Specification
COM011
COM012
COM013
Impedance
8Ω
8Ω
8Ω
Sensitivity(1W/1M)
107dB
105dB
103dB
Frequency Range
800-20KHz
1K-20KHz
1.5K-20KHz
Peak Power
80W
70W
50W
Flux Density
1.4T
1.2T
1.1T
Weight
2.2kg
1.5kg
2.2kg
Diaphragm Type
D011
D012
D013
Diaphragm Material
Titanium
Titanium
Titanium
Voice Coil Material(mm)
44
44
34
Voice Coil Diameter
Aluminium Flat Wire
Copper Flat Wire
Copper Flat Wire
Voice Coil Frame
Kapton
Kapton
Kapton



COM-010


* Impedance: 8Ω
* Sensitivity(1W/1M): 107dB
* Frequency Range: 2K-16KHz
* Peak Power: 80W
* Flux Density: 1.2T
* Weight: 2.9Kg
* Diaphragm Type: D010
* Diaphragm Material: Titanium
* Voice Coil Material(mm): 34.4
* Voice Coil Diameter: Copper Flat Wire
* Voice Coil Frame: Kapton


COM-014

* Impedance 8Ω
* Sensitivity(1W/1M) 103dB
* Frequency Range 1.5K-20KHz
* Peak Power 50W
* Flux Density 1.1T
* Weight 1.2Kg
* Diaphragm Type D014
* Diaphragm Material Titanium
* Voice Coil Material(mm) 46
* Voice Coil Diameter Aluminium Flat Wire
* Voice Coil Frame Kapton



COM-015

* Impedance 8Ω
* Sensitivity(1W/1M) 85dB
* Frequency Range 2K-16KHz
* Peak Power 10W
* Flux Density 1.2T
* Weight 0.5Kg
* Diaphragm Type D015
* Diaphragm Material Titanium
* Voice Coil Material(mm) 20.5
* Voice Coil Diameter Aluminium Flat Wire
* Voice Coil Frame Kapton


COM-016

* Impedance 8Ω
* Sensitivity(1W/1M) 93dB
* Frequency Range 2K-16KHz
* Peak Power 10W
* Flux Density 1.2T
* Weight 0.7Kg
* Diaphragm Type D016
* Diaphragm Material Titanium
* Voice Coil Material(mm) 25.4
* Voice Coil Diameter Copper Flat Wire
* Voice Coil Frame Kapton


COM-025

* Impedance 8Ω
* Sensitivity(1W/1M) 110dB
* Frequency Range 1.5-20KHz
* Peak Power 80W
* Flux Density 1.7T
* Weight 3.5Kg
* Diaphragm Type D025
* Diaphragm Material Titanium
* Voice Coil Material(mm) 72
* Voice Coil Diameter Aluminium Flat Wire
* Voice Coil Frame Kapton


COM-018

* Impedance 8Ω
* Sensitivity(1W/1M) 110dB
* Frequency Range 500-25KHz
* Peak Power 150W
* Flux Density 1.7T
* Weight 3.5Kg
* Diaphragm Type D018
* Diaphragm Material Titanium
* Voice Coil Material(mm) 75
* Voice Coil Diameter Aluminium Flat Wire
* Voice Coil Frame Kapton


COM-115A

* Titanium
* 4″Dome Tweeter
* Outer Diameter:105x105mm
* 11 Oz Magnet
* 1.75″Voice Coil(Kpt)
* 300 Watts Max
* Impedance:4/8 Ohm
* SPL:95db/W/M
* Freq.Resp.:2000Hz-30000Hz
