Model No: DS-400

Snare/Tom Microphone

Specifications:
Element:Moving Coil Dynamic
Polar Pattern:Uni-directional
Sensitivity:-54 +-3dB/Pa
Frequency Response:70Hz 13KHz
Output Impedance:500Ohm +-30%
Output Connector:Integral 3-pin XLRM type
Dimensions:
Net Weight:
Accessories:Clamp, Holder, Thread insert


Model No: DS-420

Kick Drum Microphone

Specifications:
Element:Moving Coil Dynamic
Polar Pattern:Uni-directional
Sensitivity:-58 +-3dB
Frequency Response:20Hz 15KHz
Output Impedance:250Ohm +- 30%
Output Connector:Integral 3-pin XLRM type
Dimensions:
Net Weight: 250g
Accessories:Clamp, Thread insert


Model No: CM-650

Condenser Microphone

Model No: CM-650
Element:Back Electret Condenser
Polar Pattern:Cardioid
Sensitivity:-45 +-3dB(0dB=1V/Pa at 1 KHz)
Frequency Response:50Hz - 18KHz
Output Impedance:200 +-30%
Max Input S.P.L:136dB
Self Noise:28dB
Dynamic Range:108dB
Signal/Noise Ratio:More Than 66dB
Current Consumption:Max. 0.5 mA
Power Supply:Phantom Power 48V
Net Weight:82g
Accessories:Windscreen, Holder


Condenser Microphone


DK-5SC65

Economical plastic carrying case indluding:
DS-420*1PC
DS-400*2PCS
CM-650*2PCS
Accessories

DK-7SC65

Economical plastic carrying case indluding:
DS-420*1PC
DS-400*4PCS
CM-650*2PCS
Accessories



DK-5C65

DK-5C65 includes:
1x DS-610 dynamic bass drum microphone
2x Snare/Tom microphone DS-310&320
2x CM-650 back electret overhead condenser mics.
2x Thread inserts 3/8 and 5/8 threads.
2x Clamp for Snare/Tom mic

DK-7C65

Dk-7C65 includes:
1x DS-610 dynamic bass drum microphone.
4x Dynamic Snare/Tom microphone DS-310&320
2x CM-650 back electret overhead condenser mics.
2x Windscreen
4x Clamp for Snare/Tom mic
2x Holder for condenser mic



DS-310

DS-320

DS-610
